MH-R45
Rigid strut clamp with angled top for attaching tubing and pipes to strut channels
- Material composition: Carbon steel
- Surface finish: Indoor Coated - Pre-galvanised
- Environmental conditions: Dry indoor conditions (C1) Indoor with temporary condensation (C2)
Choose options
Nominal pipe size (imperial)
- 1 in
- 2 in
- 4 in
Allowable axial load - Fx
- 0.22 kN
- 0.27 kN
- 0.67 kN
Allowable shear load - Fy
- 0.33 kN
- 0.44 kN
Allowable tensile load - Fz
- 2.67 kN
- 3.56 kN
Pack size
- 25 pc
- 50 pc
- 100 pc
Quantity
Packs
Total Pieces
1
Discounted net
From RM819.50
Technical Data
Material composition
Carbon steel
Surface finish
Indoor Coated - Pre-galvanised
Environmental conditions
Dry indoor conditions (C1) Indoor with temporary condensation (C2)
Tightening torque
7 Nm
Documents
pdf Corrosion handbook, English [ 9.4 MB ]
Features & Applications
Features
- Tightening screw at 45° angle for easy access
- One piece out of the box, simply break apart and install
- Innovative design requires no nuts for fast and easy assembly
For approval or certificate information, please see individual items.
